📖 Argus Runbook

Operational guide for diagnosing and resolving production issues using logs and metrics.

Table of Contents

• Log Interpretation
• Metric Thresholds
• Alert Investigation
• Event Investigation
• SQLite Health
• Common Failure Scenarios
• Escalation

📋 Log Interpretation

Argus uses structured log lines at INFO, WARNING, and ERROR levels.

🔍 Key Log Patterns

📊 Log Levels Summary

• INFO — Normal operational events; no action required.
• WARNING — Degraded operation (e.g., exporter skipped, device briefly offline). Monitor for recurrence.
• ERROR — Failed operation; investigate root cause. App continues running.
• CRITICAL — Severe condition (e.g., battery floor reached, startup failure). Immediate attention required.

📊 Metric Thresholds

Prometheus metrics are exposed on PROMETHEUS_PORT (default 9090). Suggested alert rules:

Tip: Set PROMETHEUS_DISABLE_LABELS=true to reduce label cardinality when monitoring many devices in a high-cardinality environment.

🔍 Alert Investigation

When an alert fires:

1. Identify the event type from the alert payload (event_type field).

2. Check recent logs for the triggering condition:

   docker logs argus-scheduler --tail 100 | grep -i "event\|battery\|offline"


3. Query the events API for the device’s event history:

   curl "http://localhost:8000/api/events?device_id=ups-main&page_size=20"


4. Check device status via NUT directly:

   upsc ups@<nut-host>


5. Trigger a manual poll to get fresh telemetry:

   curl -X POST http://localhost:8000/api/trigger \
     -H "X-Api-Key: <key>"


6. Confirm alert provider config is enabled and URLs are correct:

   curl http://localhost:8000/api/alerts


🔍 Event Investigation

on_battery

UPS switched from AC to battery power.

1. Check AC power status at the UPS location.
2. Verify upsc ups@<host> shows ups.status: OB.
3. Monitor battery_percent — if dropping, prepare for potential shutdown.
4. Expected recovery: power_restored event when AC returns.

battery_low

Battery charge is below the NUT battery.charge.low threshold.

1. Verify load on the UPS — shed non-critical loads if possible.
2. Runtime is likely < 5–10 minutes. Initiate graceful shutdowns.
3. If SHUTDOWN_BATTERY_FLOOR_PCT is reached, a shutdown_initiated event fires.

device_offline

Device missed DEVICE_OFFLINE_MISSED_POLLS consecutive polls.

1. Check network connectivity to the device host.
2. For NUT: verify upsc -l <host> responds.
3. For SNMP: snmpwalk -v2c -c public <host> to confirm reachability.
4. Check for NUT daemon restarts: systemctl status nut-server.
5. If using Docker: check host.docker.internal resolves correctly on Linux.

threshold_crossed

Load % or temperature exceeded the configured limit.

1. For load: identify processes/devices consuming power — shed non-critical loads.
2. For temperature: check cooling/airflow around the device.
3. Review THRESHOLD_LOAD_PERCENT and THRESHOLD_TEMP_CELSIUS settings.

💾 SQLite Health

Checking Database Size

du -sh data/argus.db

Checking Row Count

sqlite3 data/argus.db "SELECT COUNT(*) FROM power_snapshots;"

Manual Retention Cleanup

The SQLiteExporter runs retention automatically. To trigger manually:

sqlite3 data/argus.db \
  "DELETE FROM power_snapshots WHERE timestamp < datetime('now', '-90 days');"
sqlite3 data/argus.db "VACUUM;"

WAL Mode

Argus uses WAL (Write-Ahead Logging) for SQLite to allow concurrent reads during writes. WAL checkpoints happen automatically. If the WAL file grows unexpectedly large:

sqlite3 data/argus.db "PRAGMA wal_checkpoint(TRUNCATE);"

🚧 Common Failure Scenarios

NUT Connection Refused in Docker

Symptom: NUT poll failed: Connection refused when NUT_HOST=localhost

Cause: localhost inside the container refers to the container, not the host.

Fix:

# Linux
NUT_HOST=host.docker.internal
# (ensure extra_hosts: host.docker.internal:host-gateway in docker-compose.yml)

# macOS/Windows
NUT_HOST=host.docker.internal

# Preferred: use host LAN IP
NUT_HOST=192.168.1.10

Prometheus Metrics Not Appearing

Symptom: No data in Grafana / curl http://localhost:9090/metrics returns nothing

Checks:

1. Confirm prometheus is in ENABLED_EXPORTERS.
2. Verify PROMETHEUS_PORT matches the Prometheus scrape target.
3. Check scheduler logs: Exporter 'prometheus' initialized.

Snapshots Not Written to SQLite

Symptom: GET /api/snapshots returns an empty list or 503

Checks:

1. Confirm sqlite is in ENABLED_EXPORTERS.
2. Verify the argus-data volume is mounted on both containers.
3. Check scheduler logs for SQLiteExporter errors.
4. Check disk space: df -h.

Alert Not Delivered

Symptom: Event fired but no notification received

Checks:

1. Verify the provider is enabled in GET /api/alerts.
2. Confirm the provider URL is HTTPS and reachable from the container.
3. Check logs for Alert provider 'X' failed and the error message.
4. Use the test endpoint: POST /api/alerts/test.
5. Verify ALERT_COOLDOWN_SECONDS — the cooldown may be suppressing repeated alerts.

Scheduler Container Exits Immediately

Symptom: argus-scheduler restarts in a loop

Checks:

1. View exit logs: docker logs argus-scheduler --tail 50.
2. Look for CRITICAL messages — usually a bad API_KEY length or missing required config.
3. Fix the environment variable and restart.

🆘 Escalation

If the runbook steps do not resolve the issue:

1. Collect full container logs: docker logs argus-scheduler > scheduler.log 2>&1
2. Export last-poll diagnostics: curl http://localhost:8000/api/diagnostics
3. Open an issue at github.com/fabell4/argus with logs attached.
